• Floor Vibration is nil which keeps the machine steady.
  • All Contact part and screen made of S.S. 316 quality.
  • Easy dismantling and cleaning facility for contact parts.
  • Noiseless, Maintenance free & High Speed Model.
  • Electric Power requirement less than other Machines. Of the kind in the industries & lower energy consumption compared to reciprocating vibratory system.
  • Double & Triple deck screens with outlet and hopper for bottom deck available on request.

Technical Specification

Height 685 mm
Width 500 mm
Length 325 mm
Charging Height 685 mm
Discharge heght 456 mm
Screen size Dia 288mm
Contact part S.S.316
Non contact part S.S.304
Electricals 0.25 HP, 3 Ø ,1440 RPM A.C
Net weight 30 kg Approx.

Note: Minor Change in Dimension can be Vary without Prior Notice.
