SALIENT FEATURES
- Floor Vibration is nil which keeps the machine steady.
- All Contact part and screen made of S.S. 304 L /316 quality.
- Easy dismantling and cleaning facility for contact parts.
- Noiseless, Maintenance free & High Speed Model.
- Electric Power requirement less than other Machines. Of the kind in the industries & lower energy consumption compared to reciprocating vibratory system.
- Double & Triple deck screens with outlet and hopper for bottom deck available on request.
Technical Specification
| MODEL | SUNVS20” | SUNVS30” |
| MOTOR | 0.5 H.P. / 1440 RPM/ 3 Phase. | 0.5 H.P. / 1440 RPM/ 3 Phase |
| CHARGING HEIGHT | 750 mm. | 1250 mm. |
| DISCHARGING HEIGHT | 550 mm. | 880 mm. |
| SCREEN DIAMETER | 510 mm. | 750 mm. |
| CAPACITY / HOUR | 20 TO 100 Kgs. | 30 TO 300 Kgs. |
